ANENG AN101 Mini Digital Multimeter 1999 Counts Professional AC/DC Voltage Tester Automotive Current Tester Electrician Tools

588111

SKU: 588111 Category:
Report Abuse
Description

ANENG AN101 Mini Digital Multimeter 1999 Counts Professional AC/DC Voltage Tester Automotive Current Tester Electrician Tools

  • Hign-concerned Chemical: None
  • Operating Mode: Auto
  • Measuring Capacitance Range: AN101 Digital Multimeter
  • Operating Temperature: 0 – 40 ℃
  • DIY Supplies: ELECTRICAL
  • Measuring Resistance Range: Detection Tool
  • Certification: none
  • Origin: Mainland China
  • Model Number: ANENG AN101 Digital Multimeter
  • Measuring Inductance Range: Professional Multimetro
  • Brand Name: ANENG
  • Dimensions: Multimeter
  • DC Current: 200uA/2000uA/20mA/200mA
  • AC Current: 200uA/2000uA/20mA/200mA
  • AC Voltage: 2V/20V200V/600V
  • DC Voltage: 200mv/2V/20V200V/600V
  • Display Type: Digital display
  • ANENG Model: AN101
ANENG AN101
1999 Counts DC/AC Voltage Current Multimeter
Specification:
  • Display: LCD, 1999 counts updates 2/sec
  • Polarity Indication: “-” displayed automatically
  • Over-range Indication: “OL” displayed
  • Range select: auto or manual
  • Battery Type: 3V x 2,2032 size (not included)
  • Operation Temperature: 0℃ to 40℃, less than 80%RH
  • Storage Temperature: -10℃ to 50℃, less than 85%RH

DC Voltage (Auto ranging):

  • Range, Resolution & Accuracy
  • 200mV, 0.1mV, ±(0.8% of rdg + 5dgts)
  • 2V, 1mV, ±(0.5% of rdg + 2dgts)
  • 20V, 10mV
  • 200V, 100mV
  • 600V, 1V, ±(1.0% of rdg + 5dgts)
  • Input Impedance: 10MΩ
  • Overload Protection: 600V DC/AC rms
  • Max. Input Voltage: 600V DC

AC Voltage (Auto ranging):

  • Range, Resolution & Accuracy
  • 2V, 1mV, ±(1.2% of rdg + 3dgts)
  • 20V, 10mV
  • 200V, 100mV
  • 600V, 1V, ±(1.2% of rdg + 8dgts)
  • Input Impedance: 10MΩ
  • Frequency Range: 40Hz ~ 400Hz
  • Overload Protection: 600V DC/AC rms
  • Response: Average, calibrated in rms of sine wave
  • Max. Input voltage: 600V AC rms

DC Current:

  • Range, Resolution & Accuracy
  • 200µA, 0.1µA, ±(0.8% of rdg + 5dgts)
  • 2000µA, 1µA
  • 20mA, 10µA
  • 200mA, 100µA
  • Overload Protection: F0.5A/600V fuse
  • Max. Input Current: 500mA
  • Voltage Drop: 200µA and 20mA ranges: 20mV
  • 2000µA and 200mA ranges: 200mV

AC Current:

  • Range, Resolution & Accuracy
  • 200µA, 0.1µA, ±(1.0% of rdg + 5dgts)
  • 2000µA, 1µA
  • 20mA, 10µA
  • 200mA, 100µA
  • Overload Protection: F0.5A/600V fuse
  • Max. Input Current: 500mA
  • Voltage Drop: 200µA and 20mA ranges: 20mV
  • 2000µA and 200mA ranges: 200mV
  • Frequency Range: 40Hz ~ 400Hz
  • Response: Average, calibrated in rms of sine wave

Package included:

  • 1 x Digital Multimeter (battery is not included)
  • 1 x Test Leads

Note:

  • Please allow 0-1cm errors due to manual measurement.
  • Item color displayed in photos may be showing slightly different on your computer monitor since monitors are not calibrated same.
